Automatic beverage milk juice water liquid glass bottle can plastic bottling packing filling machine

packaging line

Automatic beverage milk juice water liquid glass bottle can plastic bottling packing filling machine

Features

1. Filling form: servo-driven multi-head piston filling;

2. The maximum filling temperature is within 70℃;

3. Material in contact with liquid parts: 304# stainless steel and food grade PVC;

4. The filling nozzle is equipped with anti-dripping device to ensure the filling without drawing and leakage;

5.The compatibility of the equipment is strong, no need to replace parts, can quickly adjust and replace the bottle of different shapes and specifications, can meet the production requirements of multiple varieties and specifications.

Product Details

Product Description

						These machines are used for liquid, sauce, paste filling.


Specification
Packaging Type	Cans, Bottles, Jars
Power	220V/380V, 50/60Hz
Brand Name	Sanpong
Certification	CE
Filling speed	20-80pcs/min (5pcs/head/min)
Filling Accuracy	±1%
Material	Stainless Steel (304/316)
Number of filling heads	4-16 heads
Filling capacity	50-1000ml
Filling accuracy	±1%
Bucket capacity	150L

Features

1. Filling form: servo-driven multi-head piston filling;

2. The maximum filling temperature is within 70℃;

3. Material in contact with liquid parts: 304# stainless steel and food grade PVC;4. The filling nozzle is equipped with anti-dripping device to ensure the filling without drawing and leakage;

				        Can set up the production line according to your special requirements.


Product Details

						The filling nozzle is made of 304 stainless steel, corrosion resistant, in line with GMP production requirements, the hose is made of PVC, the temperature range :-10℃~+90℃


						The piston is driven by the servo to extract the material into the measuring cylinder, and then the piston is driven by the servo to fill the container through the material pipe. The filling amount is determined by adjusting the servo position parameters, which is convenient to adjust



							The overall program control adopts PLC+ touch screen, filling volume and filling speed adjustment is convenient, quick and simple.

						The machine has included automatic piston feeding pump;


Application

Product range

					Widely use in food industry, beverage industry, pharmaceutical industry and chemical industry.

It's suitable for all kinds of liquid, paste, sauce filling, such as honey, chili sauce, tomato sauce, pearl milk tea, orange juice andother materials filling, it's high versatility;

			Guangzhou Sanpong Machinery Industrial Co.,Ltd. is a joint-stock enterprise specialized in manufacture and sales of various packaging equipment for quantification filling, sealing and labeling. Th company is integrated with research, design, production and sales and the products are sold well all over the world mainly for the packages of food, beverage, medical and chemical industry. Located in Guangzhou city, a core city in south of China, the company has developed into a nationally-known packaging machinery manufacturer and earned good reputation based on the good technology and service. The company has been paying close attention to management, quality control and after sales services and through unremitting efforts made by our production and marketing team, we have expanded our business to over 50 countries and the brand competitiveness is still increasing.


Our Workshop
